NI 9866
  NI 9866

  1-Port NI-XNET LIN C Series Module

  起价RMB 5,330【含税价:6237】

  1-port LIN interface (20 kbit/s per port) with onboard NXP TJA1028 transceiver

  NI-XNET driver for developing frame and signal applications in LabVIEW, LabWindows?/CVI, and C/C++

  NI-XNET device-driven DMA engine couples the LIN bus to host memory to minimize message latency

  Integrated support for importing and using signals from LDF databases

  Master and slave support; hardware-timed scheduling for master tasks

  In CompactRIO, use in NI cRIO-911x/908x/906x chassis with LabVIEW FPGA installed.

  概况:

  NI 9866 is a 1-port, local interconnect network (LIN) NI CompactDAQ and NI CompactRIO interface for developing CAN applications in NI LabVIEW, NI LabWindows/CVI, and ANSI C/C++. As part of the NI-XNET platform, the NI 9866 works well for applications requiring high-speed manipulation of hundreds of LIN frames and signals. You can perform this manipulation while taking other data acquisition measurements in the same NI CompactDAQ hardware platform or while performing low-level field-programmable gate array (FPGA) control and embedded monitoring in the same NI CompactRIO chassis.

  NI 9866 and NI-XNET products are ideal for standardizing on LIN communication. By using the same software API for programming networks on PXI, PCI, NI CompactDAQ, and NI CompactRIO, development time is significantly reduced through maximum code reuse. Real-time testing applications like hardware-in-the-loop testing and simulation are also ideal for the NI 9866 because it is part of the NI-XNET family of products and works with the NI VeriStand software environment for configuring real-time testing applications.

  NI-XNET: One API, Many Embedded Networks and Form Factors

  The NI-XNET platform combines a series of high-performance CAN, LIN, and FlexRay interfaces with the NI-XNET API, a common set of easy-to-use functions for reading and writing CAN, LIN, and FlexRay frames and signals in many different platforms including PXI, PCI, NI CompactDAQ, and NI CompactRIO.
 Carrier Support

  For the NI CompactDAQ platform, the NI 9866 works with NI cDAQ-9171, cDAQ-9174, cDAQ-9178, cDAQ-9181, cDAQ-9184, cDAQ-9188, and cDAQ-9191 chassis.

  For the NI CompactRIO platform, the NI 9866 works with the cRIO-911x reconfigurable chassis using a cRIO-901x or cRIO-902x controller, or in a cRIO-906x or cRIO-908x integrated chassis.

  The mark LabWindows is used under a license from Microsoft Corporation. Windows is a registered trademark of Microsoft Corporation in the United States and other countries.

  规范概要:

   若使用NI 9866,您需配备所有项目。若您已经拥有C系列系统,请选择选项1;若您尚未拥有机箱、控制器或软件,请选择选项2。

  了解为何需要系统中的各个项目

  C系列系统

  1 电缆NI 9866机箱控制器软件

  仅NI 9866和附件

  选项1:仅NI 9866和附件

  NI 9866 - 781963-01数量RMB 5,330 /每款【含税价:6237】

  必要附件

  电缆 - 9针D-Sub母口

  NI CAN No Termination Cable (1m) - 193128-01

  选择长度:1m2m数量RMB 250 /每款【含税价:293】

  可选附件

  Connectivity Accessories

  CAN Breakout Box - 780041-01数量RMB 3,345 /每款【含税价:3914】

  选项2: C系列系统
